PRS Maximum Inlet Pressure:
250bar (3600psig)
Minimum Delivery Pressure (Flow Dependent):
7Bar (98psig)
Outlet Pressure:
Minimum 1Bar (14psig)
Operating Temperature:
20degC +- 10deg C
Sizes:
500nm3hr
1000nm3hr
2000nm3hr
3000nm3hr
Standard Features:
- All in one boiler/heat exchanger system
- Two stage regulating system
- Sate of the Art pressure control Valve systems
- Expansion tubes
- Dual regulators
- Interstage relief Valves
- Pipework and related Valving
- Header Tank
- Single piece skid
- Ex rated electrical Control Box
- Ex rated transmitters
- Ex rated Heating element or Separate Gas Boiler Skid
Option features:
Dual Regulator Line
Scada control system
Bypass Line Valve system
Three stage regulating system
Flow Meter
Inline Filter Assemblies
